1.1 Quality Philosophy

Jingye Lide upholds the quality philosophy of "Quality is Dignity," embedding quality consciousness throughout the entire process — from raw material sourcing to final product delivery. We firmly believe that every powder particle carries our customers' trust, and only consistently reliable products earn long-term partnerships in precision manufacturing.

Our quality management is not achieved by inspection alone — it is engineered in, manufactured in, and prevented in. From alloy composition optimization and real-time atomization parameter monitoring, to precision classification and multi-dimensional product verification, every process step is governed by quantified quality standards and a fully traceable accountability system.

1.2 Quality Management Process

1.2.1 End-to-End Quality Control Framework

1.2.2 Key Testing Capabilities

1.2.3 Quality Management System

ISO 9001:2015 certified quality management system

IATF 16949-equivalent control standards for automotive supply chain

SPC (Statistical Process Control) for critical quality characteristics

Full batch traceability: raw material heat number → production lot → inspection report → customer receipt

Three-tier inspection system: First-piece inspection + In-process patrol inspection + Last-piece comparison

1.2.4 Quality Commitment

CoA (Certificate of Analysis) provided with every shipment

±0.1% tolerance on critical alloying elements

D50 particle size deviation controlled within ±1.0 μm

24-hour response to quality complaints and 48-hour preliminary analysis report

Sample re-inspection service for quality disputes

2.1 Core Technology: Water-Gas Combined Atomization

Jingye Lide employs proprietary ultra-high-pressure water-gas combined atomization technology. This process integrates the advantages of both water atomization (high cooling rate, high fine-powder yield) and gas atomization (superior sphericity, low oxygen content), making it one of the most optimized industrial routes for MIM powder production.

Process Principle

Under inert gas protection, molten metal is ejected through a specialized nozzle, initially broken up by high-pressure inert gas (N₂/Ar), then secondarily atomized by high-pressure water jets. The metal droplets solidify into fine, near-spherical powder under extremely high cooling rates. The resulting powder combines near-spherical morphology with low oxygen content while retaining the high fine-powder yield advantage of water atomization.

Key Advantages

1. Near-spherical morphology — Excellent flowability and high tap density for uniform feedstock and mold filling

2. Low carbon and low oxygen — Inert gas protection and strict moisture control ensure powder cleanliness

3. Controllable PSD — D50 precisely adjustable from 6 μm to 12 μm to meet diverse product requirements

4. Batch-to-batch consistency — 12 standardized production lines ensure high reproducibility

5. High fine-powder yield — Industry-leading fine powder ratio with D90 ≤ 25 μm

2.2 Manufacturing Process Flow

Raw Material Inspection → Alloy Melting → Water-Gas Atomization → Wet Powder Collection → Wet Powder Drying → Sieving & Classification → Blending & Homogenization → Final QC → Vacuum Packaging → Warehouse & Shipment

Key Process Steps

2.3 Production Capacity

2.4 R&D Capabilities

Custom powder formulation: Reverse-engineer alloy compositions based on target sintered-part properties

Feedstock development support: Provide feedstock formulation references and injection parameter recommendations

Full-process validation: In-house injection molding pilot line for closed-loop verification from powder → feedstock → injection → debinding → sintering → mechanical testing

Continuous process improvement: Ongoing optimization of tap density, PSD, and oxygen content based on customer feedback

3.1 Industry Applications

3.1.1 Consumer Electronics

3.1.2 Medical Devices

3.1.3 Automotive Parts

3.1.4 Aerospace

3.1.5 Power Electronics

3.1.6 Precision Tools & Hardware

3.2 Service Model

3.2.1 Standard Product Supply

Standard MIM powders with CoA provided for every batch, ensuring stable lead times and reliable supply for volume production.

3.2.2 Custom Powder Development

Tailored chemical composition and particle size distribution based on customers' injection molding, debinding, sintering conditions, and target part performance requirements.

3.2.3 Full-Process Technical Support

Feedstock formulation recommendations

Injection molding parameter optimization

Debinding and sintering profile recommendations

Sintered-part defect analysis and improvement

3.2.4 End-to-End Validation Service

On our in-house injection molding pilot line, we conduct full closed-loop validation for customer grades:

Powder → Feedstock → Injection Molding → Catalytic/Solvent Debinding → Vacuum Sintering → Mechanical Testing

What we deliver is not just powder, but a validated end-to-end MIM manufacturing solution.

3.3 Why Jingye Lide?
